Коммутатор Ethernet управляемый L2+ TS2210M-48T4X TELSAR

Управляемый L2+ коммутатор TS2210M-48T4X оснащён 48 портами 100/1000Base-T RJ45 и 4 портами 1G/2.5G/10GBase-X SFP+. Пропускная способность 176 Гбит/с. Управление и настройка через веб-интерфейс или CLI (командная строка консоли). Блок питания 220 VAC, потребление питания 40 Вт при полной нагрузке. Поддерживает технологии резервирования G.8032 ERPS, MSTP/RSTP/STP, статическую маршрутизацию IPv4/IPv6, DHCP-сервер и надежную функцию управления и безопасности уровня 2. TS2210M-48T4X — это комплексное решение, которое предлагает сквозное качество обслуживания (QoS), а также гибкое и расширенное управление и настройки безопасности. Оно способно удовлетворить требования к высокой скорости, безопасности и интеллектуальности для небольших и средних корпоративных сетей, при этом оставаясь экономически эффективным. Мощные функции сетевой безопасности в TS2210M-48T4X обеспечивают эффективную передачу данных и управление трафиком для интернет провайдеров и корпоративных VoIP-сетей, а также для потоковой передачи видео и многоадресной рассылки приложений. Особенности коммутатора Ethernet L2+ управляемого TELSAR Интерфейсы: 4*1G/2.5G/10G SFP+ порта, 48*10/100/1000BASE-T RJ45 портов, 1*RJ45 консольный интерфейс *RJ45 для базового управления и настройки коммутатора. Чипсеты: Marvell AC5 series2GHz чипсет CPU, Marvell AC5 series чипсет коммутации, 512MB RAM и 512MB flash Функции L3: IPv4/IPv6 static routing, DHCPv4/ DHCPv6 client, DHCPv4 relay, DHCP relay. Особенности портов : port aggregation, IEEE802.3x flow control, port isolation, port mirroring, loop detection and broadcast storm suppression VLAN: 1Q tagged VLAN, mac based VLAN, IP based VLAN, protocol based VLAN, voice VLAN и private VLAN. QinQ: Supports port-based, VLAN-based and flow-based QinQ GVRP/LLDP/SPAN/RSPAN/DHCPv4 snooping Сетевые протоколы L2: STP, RSTP, MSTP, G.8032 ERPS protocol, single ring, sub ring Многоадресная рассылка (Multicast) : IGMP snooping, IGMP v1, v2, v3, PIM-SM Качество обслуживания (QoS) : QoS class, remarking, Supports SP, WRR queue scheduling, Ingress/Egress port-based rate-limit and policy-based QoS Безопасность : ACL, 802.1x, port-security, IP source guard, ARP-check, DAI, anti-gateway ARP spoofing, Ddos attack protection, telnet/SSH/HTTP/HTTPS user access control and AAA. Надежность : Loop detect based on port or VLAN, the Ethernet in the first mile 802.3ah Управление : Supports IPv4/IPv6 dual stack management, system log management, user management, login service management, firmware management, web management, CLI management, fault detection, DNS, NTP, sFlow, SNMP, MQTT, RMON and dual partition management. Протоколы приложений : telnet server, telnet client, SCP, SFTP, SSH server, TACACS и TFTP client Технические характеристики TS2210M-48T4X Модель TS2210M-48T4X Interface Fiber ports Copper RJ45 ports 4 48 Ethernet 48*10/100/1000Base-T RJ45 4*1G/2.5G/10GBase-X SFP+ CPU Marvell AC5 series 1.2GHz Size of RAM 512MB Size of Flash 512MB Switch chip model Marvell AC5 series Management port 1*RJ45 Console port (115200,8,N,1) Standard IEEE 802.3 10Base-T Ethernet IEEE 802.3u 100Base-TX Ethernet IEEE 802.3ab 1000Base-T Ethernet IEEE 802.3z 1000Base-X Ethernet IEEE 802.3ae 10Gigabit Ethernet IEEE802.3x Flow Control and Back Pressure IEEE 802.1D Spanning Tree Protocol IEEE 802.1w Rapid Spanning Tree Protocol IEEE 802.1Q VLAN ITU-T G.8032 ERPS IEEE 802.1X Port Authentication Network Control IEEE 802.1ab LLDP IEEE 802.3ad LACP LED Indicators PWR (Power indicator) Off: the device is power off or failed On: the device power on is normal SYS (System status indicator) Blinking: device initialization On: device on normal operation 1-48 (Copper ports indicators) Green Off: ports link down On: ports link up Blinking: data on TX/RX 1-48 (Copper speed indicators) Yellow Off: ports on 10/100M On: ports on 1000M 49-52(Fiber ports indicators) Green Off: ports link down On: ports link up Blinking: data on TX/RX Power parameter Input voltage 1* AC 100-240V input on default 1* DC 36-72V input optional 2* AC 100-240V input optional 1* AC 100-240V input + 1* DC 36-72V input optional Total power consumption Full loading ≤40W Over-current protection Support Layer 2 switching Port aggregation Support GE port aggregation Support 2.5GE aggregation Support 10GE aggregation Support static aggregation Support LACP dynamic aggregation Up to 64 aggregation groups and up to 8 ports per group Port features Support IEEE802.3x flow control Support interface counters Support port isolation Port mirroring (One-to-One, Many-to-One) Support loop detection (Port-based; VLAN-based) Support broadcast storm suppression (broadcast; unknown multicast; unknown unicast) VLAN IEEE802.1Q tagged VLAN Mac based VLAN IP based VLAN Protocol based VLAN Voice VLAN, specially divide VLAN for user voice data flow Private VLAN, divide a VLAN broadcast domain into multiple subdomains to form a double-layer VLAN structure VLAN range: 1-4094 Support access mode/trunk mode/hybrid mode Mac-address table management Support static Mac-address management Support dynamic Mac-address Management Support filtering Mac-address Support MAC limit based on port and VLAN Support MAC flapping based on port and VLAN 16K Mac-address table size GVRP Normal mode Fixed mode Forbidden mode QinQ Port-based QinQ VLAN-based QinQ VLAN mapping Flow-based QinQ LLDP Link Layer Discovery Protocol Med SPAN Number of Sessions: 7 Many-to-one RSPAN Remote Switch Port Analyzer MSTP 802.1D STP 802.1W RSTP 802.1S MSTP BPDU Guard Number of Single Ring Device Connections: 20 ERPS G.8032 Major ring Sub ring Recovery time ≤20ms Number of Single Ring Device Connections: No limit QoS QoS Class, Remarking Support SP, WRR Queue Scheduling Ingress Port-based Rate-limit Egress Port-based Rate-limit Egress port-queue shaper Policy-based QoS Port Queue Numbers: 8 DHCPv4 Snooping DHCP snooping trust port DHCP snooping option-82 DHCP snooping circuit-id and remote-id customized L2 Multicast IGMP IGMP v1, v2, v3 IGMP Snooping Internet Group Management Protocol Snooping Fast Leave Multicast Table Size: 1K PIM-SM Protocol Independent Multicast-Sparse Mode Security features ACL IP Standard ACL IP Extended ACL MAC extend ACL IPv6 ACL Time Range ACL apply on VLAN ACL Entrys, include input and output 802.1x Port access control Mac-address access control RADIUS server Port-security Port-security IP source guard IP Source Guard, Port-based IP/Mac Binding Access ARP-check Support ARP-check and ARP packet filtering for illegal users DAI Dynamic ARP Inspection Anti-gateway ARP Spoofing Prevent Gateway ARP Spoofing Ddos Ddos attack protection Access control Support Telnet/SSH/HTTP/HTTPS user access control AAA RADIUS authentication access switch TACACS authentication access switch Authorization Reliability Loop Detect Loop detect, based on port or VLAN EFM The Ethernet in the first mile, 802.3ah Management & Maintenance functions Dual Stack IPv4 and IPv6 Dual Stack Management System Log Management Syslog Level 7 to 0 Corresponding Debug/Info/Notice/Warning/Err/Critical/Alert Support connecting up to 3 Servers For IPv4 and IPv6 User Management Support password protection, support MD5/SHA256/SHA512 algorithm Local Management of User Privilege Remote authorization by RADIUS or TARCAS Enable privilege protection User password complexity requirements User login fail protection User Privilege Level 0 to 15 Login Service Management Up to 8 users online simultaneously Access control based on IPv4 or IPv6 ACL Firmware Management Firmware upgraded by WEB Firmware upgraded by CLI Dual partition Web Management Web Management Support HTTP V1.1 Support HTTPS For IPv4 and IPv6 CLI management Console/Telnet command line management Fault Detection Ping/Traceroute, For IPv4 and IPv6 Dying gasp optional Optical transceiver DDM One click fault information collection Cable detection DNS Domain Name System NTP Network Time Protocol, For IPv4 and IPv6 Support domain name configuration Configuration Import /Export FTP/TFTP based remote configuration import and export sFlow Sampled flow SNMP Version SNMPV2C/V3 MQTT Message Queuing Telemetry Transport RMON Support RMON (Remote Monitoring) alarm Dual partition management Support dual partition switching Application Protocol Functions Telnet server Support telnet server for IPv4 and IPv6 Telnet client Support telnet client for IPv4 and IPv6 SCP (Secure Copy Protocol) SCP client/server for IPv4 and IPv6 SFTP sftp client/server for IPv4 and IPv6 SSH server Support login based on user password-SSH2, support IPv4, IPv6 Support public key-based login TACACS Support TACACS (the terminal access controller accesses the control system) TFTP Support TFTP Client Layer 3 features Static Route Support VLAN interface and route port IPv4 static routing table entry configuration ARP dynamic learning and static configuration IPv6 static routing table entry configuration Neighbor discovery and static configuration Routing prefix table size 4k for IPv4, for IPv6 divide by 4 DHCPv4 Client Dynamic host configuration protocol for IPv4 DHCPv6 Client Dynamic host configuration protocol for IPv6 DHCPv4 Relay DHCP Relay for IPv4 DHCPv4 Server DHCP Server for IPv4 Switching features Switching capacity 176Gbps Packet forwarding rate 130.944Mpps MAC address table 16K VLAN 4K Buffer 12Mbit Forwarding delay <5us Jumbo Frame Support 10Kbytes MDX/MIDX Support Watchdog Support Mechanical structure Installation method Desktop; Rack-mount Dimension(W*D*H)mm 440*300*44mm Weight 4.50kg Operating environment Operating temperature 0℃~ +50℃ Storage/transportation temperature -10℃~ +70℃ Relative humidity Operation humidity: 10%-90%RH Storage humidity: 5%-95%RH Protection Surge protection of power: 4KV Surge protection of Ethernet ports: 4KV ESD: Contact 6kV, Air 8kV Certification CE/RoHS/FCC MTBF ＞100,000 hours Warranty 3 years
